2578 Square - with square optics
Installation type
Ceiling
Application usages
Description
Today, lighting is asked to do more than ever. To effectively illuminate a room, in addition to providing the necessary amount of light, proper attention must also be paid to aesthetics, luminaire design and light distribution. Without forgetting sustainable energy consumption. Square is the new LED luminaire designed to always provide the best lighting quality, with maximum reliability in every context, whether outdoor or indoor.In the wall-mounted version, with direct and indirect light, Square ensures maximum functionality and aesthetics with very low consumption, in different versions to achieve the best light distribution. The sturdiness of the materials, with a die-cast aluminum housing and tempered glass diffuser resistant to thermal shock and impact, also makes this product ideal for outdoor use.It's easy installation, without the need to open the fixture, makes Square LED particularly suited to illuminate a facade with class and elegance. The Square range also includes a spotlight version, with lens or fully adjustable square optics to achieve the desired lighting scenario.Luminaires are equipped with LEDs that ensure a very long lifespan, low consumption and high light quality.
Versions
Code | Wiring name | Kg | Lumen Output - K - CRI | Beam angle | TotW | Colour |
---|---|---|---|---|---|---|
CLD | 2.6 kg | 4440 lm - 4000 K - 80 | 90 ° | 40 W | White | |
CLD | 2.6 kg | 4440 lm - 4000 K - 80 | 90 ° | 40 W | Graphite |
Dimensions
The reported luminous flux is the flux emitted by the light source with a tolerance of ± 10% compared to the indicated value. The W tot column indicates the total wattage absorbed by the system without exceeding 10% of the indicated value.
