Disano

1574 Square - direct-indirect light

Installation type

Ceiling

Application usages

Outdoor

Today, lighting is asked to do more than ever. To effectively illuminate a room, in addition to providing the necessary amount of light, proper attention must also be paid to aesthetics, luminaire design and light distribution. Without forgetting sustainable energy consumption. Square is the new LED luminaire designed to always provide the best lighting quality, with maximum reliability in every context, whether outdoor or indoor.In the wall-mounted version, with direct and indirect light, Square ensures maximum functionality and aesthetics with very low consumption, in different versions to achieve the best light distribution. The sturdiness of the materials, with a die-cast aluminum housing and tempered glass diffuser resistant to thermal shock and impact, also makes this product ideal for outdoor use.It's easy installation, without the need to open the fixture, makes Square LED particularly suited to illuminate a facade with class and elegance. The Square range also includes a spotlight version, with lens or fully adjustable square optics to achieve the desired lighting scenario.Luminaires are equipped with LEDs that ensure a very long lifespan, low consumption and high light quality.

CodeWiring nameKgLumen Output - K - CRITotWColour
CLD2.2 kg3309 lm - 4000 K - 8025 WWhite
CLD2.2 kg3178 lm - 2200 K - amber26 WWhite
CLD2.2 kg3309 lm - 4000 K - 8025 WGraphite
CLD2.2 kg3178 lm - 2200 K - amber26 WGraphite
CLD2.2 kg3143 lm - 3000 K - 8025 WWhite
CLD2.2 kg3143 lm - 3000 K - 8025 WGraphite

The reported luminous flux is the flux emitted by the light source with a tolerance of ± 10% compared to the indicated value. The W tot column indicates the total wattage absorbed by the system without exceeding 10% of the indicated value.
